24/04/2024

LTS1500-10M-GS/PVC-BK : LTS1500-10M
Art.-No. 166-90385 | LTS1500-10M-GS/PVC-BK |  Details

Spiral-wound galvanized steel core with an interlocking design delivers high degree of compression strength and impact resistance.

    Add to watchlist
    Downloads
    Colour Black (BK)
    Material Galvanised Steel (GS), Polyvinylchloride (PVC)
    Pack Cont. 10.0m
    Package Content packed in reel
    PART DESCRIPTION LTS1500-10M-GS/PVC-BK
    Bending Radius min. (R) 230mm
    Diameter (D) 40.4mm
    Length (L) 10.0m
    Nominal ∅ 50.0mm
    Nominal ∅ 1.5"
    Outside Ø (OD) 47.9mm
    Outside ∅ (OD) 1.89"
    Weight 1240g/m
    ∅ D 1.59"
    CSA Certified No
    Flammability EN IEC 61386-1
    Halogen-free No
    Operating Temperature -20 °C to +105 °C
    Self extinguishing Yes
    Specifications
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) No
    UV-Stabilised No
    Country of Origin GB
    GTIN-13 / EAN 4031026520575
    Packaging 1 - Weight (kg) 12.4kg
    Reel Length 10.0m
    Reel Length 32.8ft
    UNSPSC Key 39131706
    Metal conduits Metal conduits

    Metal conduits

    Metal conduits from HellermannTyton: Standard metal conduits, coated metal conduits, liquid tight metal conduits and matching metal conduit fittings. Discover now!
