Spiral reinforced conduit, nom⌀42mm, OD=42.5mm, ID=35.5mm, orange, 25.0m


Art.-No. 166-90955

| HG-SW1253-PA6-OG

 |

Copied

    Add to watchlist
    Downloads
    Colour Orange (OG)
    Material Polyamide 6 (PA6)
    PART DESCRIPTION HG-SW1253-PA6-OG
    Package Content 25.0m
    Package Content packed in reel
    Type HG-SW1253
    Inner Diameter D (Imperial) 1.40"
    Inside ⌀ (ID) 35.5mm
    Length (L) 25.0m
    Nominal ⌀ 1-1/4"
    Nominal ⌀ 42mm
    Outside ⌀ (OD) 42.5mm
    Outside ⌀ (OD) 1.68"
    CE Certification No
    CSA Certified No
    Flammability UL 94 V2
    Halogen-free Yes
    Operating Temperature -40 °C to +120 °C
    ROHS compliant Yes
    Specifications
    Country of Origin GB
    GTIN-13 / EAN 4031026645933
    Reel Length 82.0ft
    Reel Length 25.0m
    ETIM 7.0 Key EC001175
    ETIM 8.0 Key EC001175
    ETIM 9.0 Key EC001175
    UNSPSC Key 39131601
