Convoluted Tubing
Art.-No. 169-60311
| CTPFR1120-PE-FR-GY
Copied
- Split side is ideal for applications where braided tubing or spiral wrap may be difficult to install.
- Tubing provides full coverage where spiral wrap or other coverings may not be suitable.
- In harsh applications the tubing provides resistance to crushing, impact, and abrasion.
- Tubing offers excellent protection against automotive fluids, vibration wear, water, snow, ice, and the effects of heat, cold, and sunlight on cables and wires.
| Brand Family | CTPFR-Series |
| Color | Gray (GY) |
| Description | HellermannTyton’s Convoluted Tubing, also known at Split Loom Tubing, provides an efficient method of routing and protecting wire harness assemblies, while reducing the chance of installation damage. With a split down the side where you can insert your wire harness, you can just easily install Convoluted Tubing without removal of the entire assembly. It can also serve to protect valuable hoses and cables. Convoluted tubing offers excellent protection against vibration wear, water, snow, ice and the effects of heat, cold and sunlight on cables and wires. The Polyethylene flame retardant material provides additional protection that is suitable for applications requiring a self-extinguishing material and complies with UL 94 V2 standards. |
| PART DESCRIPTION | CTPFR1120-PE-FR-GY |
| Packaging Type | carton |
| Part No. | 169-60311 |
| Short Desc. | Convoluted Tubing, Flame Retardant, Slit, 1.50" Dia, PE, Gray, 150 ft/ctn |
| Type | CTPFR1120 |
| UV Resistant | No |
| Diameter (imperial) | 1.947" |
| Diameter (metric) | 49.45mm |
| Diameter 2 (imperial) | 1.647" |
| Diameter 2 (metric) | 41.83mm |
| Inner Diameter (imperial) | 1.647" |
| Inner Diameter 2 (metric) | 41.83mm |
| Length (imperial) | 150.0ft |
| Length (metric) | 45.7m |
| Max. Bundle Diameter (imperial) | 1.64" |
| Max. Bundle Diameter (metric) | 41.8mm |
| Min. Bundle Diameter (imperial) | 0.1" |
| Min. Bundle Diameter (metric) | 1.0mm |
| Nominal Diameter (imperial) | 1.5" |
| Nominal Diameter (metric) | 38.1mm |
| Outside Diameter (imperial) | 1.947" |
| Outside Diameter (metric) | 49.45mm |
| Trade Size | 1-1/2 " |
| Wall Thickness (imperial) | 0.006" |
| Wall Thickness (metric) | 0.152mm |
Download
| CE Certification | No |
| CSA Certified | No |
| Flammability | UL 94 V-2 |
| Halogen Free | No |
| Material | PE-FR |
| Material | Polyethylene, flame retardant (PE-FR) |
| Operating Temperature | -40°F to +185°F (-40°C to +85°C) |
| Prop65 Warning | No |
| REACH Conformity | Yes |
| ROHS compliant | Yes |
| UL Listed (US and Canada) | No |
| UL Listed (US) | No |
| UL Recognized (US and Canada) | No |
| UL Recognized (US) | No |
