02/07/2026

Corrugated tubing, nom⌀16.00mm, OD=21.26mm, ID=16.23mm, black, 228.60m


Art.-No. 169-60106

| CTPPFR580-PPFR-BK

 |

Copied
Flame retardant tubing provides full coverage where spiral wrap or other coverings may not be suitable.

    Add to watchlist
    Downloads
    Colour Black with Blue Stripe (BKSTBL)
    Material Polypropylene, flame retardant (PPFR)
    PART DESCRIPTION CTPPFR580-PPFR-BK
    Package Content 228.60m
    Package Content packed in carton
    Type CTPPFR580
    UV-Stabilised No
    Variant Slit
    ⌀ (D2) 16.23mm
    ⌀ D 0.837"
    ⌀ D2 0.639"
    Diameter (D) 21.26mm
    Inner Diameter D (Imperial) 0.639"
    Inside ⌀ (ID) 16.23mm
    Length (L) 228.6m
    Nominal ⌀ 0.63"
    Nominal ⌀ 16.00mm
    Outside ⌀ (OD) 21.26mm
    Outside ⌀ (OD) 0.837"
    Outside ⌀ (OD2) 0.837"
    Outside ⌀ (OD2) 21.26mm
    Wall (WT) 0.127mm
    Wall (WT) 0.005"
    CE Certification No
    CSA Certified No
    Flammability self-extinguishing in 60 seconds
    Halogen-free No
    Operating Temperature -40 °C to +125 °C
    ROHS compliant Yes
    Specifications
    UL Listed (US and Canada) No
    UL Listed (US) No
    UL Recognized (US and Canada) No
    UL Recognized (US) No
    Country of Origin CA
    GTIN-13 / EAN 4031026739656
    Packaging 1 - Qty 1
    Packaging 1 - Type carton
    Packaging 1 - Weight (kg) 13.608kg
    UNSPSC Key 39131601
