23/02/2026

Label, self laminating, weather resistant/chemical resistance, white, thermal transfer print, 38.1x25.4mm, H2=188.7mm, 500pcs.
Art.-No. 596-96260 | PW.50W1-V-WH

Copied

    • Paint Mask Labels provide permanent paint protection but can still be removed at any time when required.
    • Paint Mask Labels withstand chemicals and heat to survive the painting process.
    Add to watchlist
    Downloads
    Application The use of our specially formulated adhesive labels printed on thermal transfer printers give the highest quality print clarity. The range of materials are complemented by ribbons developed to suit the needs of most users.
    The production of labels is very simple. All that is needed is the required label to be selected from our industry leading software TagPrint Pro.
    Color White (WH)
    Description HellermannTyton thermal transfer self-laminating Paint Mask Labels are conformable with a white printable surface followed by a clear tail that laminates the printed text when applied to a wire or cable. The labels utilize an aggressive acrylic adhesive that allows the label to bond to large and small diameter wires.
    Key product features weather resistant, chemical resistance
    PART DESCRIPTION PW.50W1-V-WH
    Packaging Type pack
    Part No. 596-96260
    Print Method thermal transfer print
    Short Desc. Paint Mask Label, 1.0" X 1.0" X 7.438", 1 Across, Vinyl, White, 500/RL
    Technical Description Paint Mask Label, 1.0" X 1.0" X 7.438", 1 across,1 piece design, .50" cable diameter, Vinyl, White, 500/RL
    Type PW.50W1
    UV Resistant No
    Height (imperial) 1.5"
    Height (metric) 38.1mm
    Height 2 (imperial) 7.43"
    Height 2 (metric) 188.7mm
    Liner Width (imperial) 3.0"
    Liner Width (metric) 76.2mm
    Max. Bundle Diameter (imperial) 0.62"
    Max. Bundle Diameter (metric) 15.8mm
    Min. Bundle Diameter (imperial) 0.37"
    Min. Bundle Diameter (metric) 9.52mm
    Printable Area Height (imperial) 1.5"
    Printable Area Height (metric) 38.1mm
    Thickness (metric) 64.0µm
    Width (imperial) 1.0"
    Width (metric) 25.4mm
    Adhesive Acrylic
    Adhesive Operating Temperature -51°F to +200°F (-46°C to +93°C)
    CE Certification No
    CSA Certified No
    Halogen Free No
    Material V
    Material Vinyl (V)
    Minimum Application Temp. +50°F (+10 °C)
    Operating Temperature -40°F to +194°F (-40°C to +90°C)
    Prop65 Warning No
    REACH Conformity Yes
    ROHS compliant Yes
    UL File Number [Logo] MH18396 [RU]
    UL Listed (US and Canada) No
    UL Listed (US) No
    UL Recognized (US and Canada) No
    UL Recognized (US) Yes
    Customs Number (Schedule B) 3919102055
    Harmonized Tariff Schedule Code 3919.10.2055
    Labels per Column 1
    Labels per Row 1
    Packaging 1 - Weight (kg) 0.68kg
    Pkg. Qty. 500
    Pkg. Qty. 500Pieces
