Adhesive Labels : TAG61-121W254SM

Article number: 558-00052

Features

The thermal transfer print guarantees a very clear and detailed image for use with graphics, single or sequential characters and especially barcodes. Helatag® labels offer the choice for smear-resistant, ultraviolet-resistant and chemical-resistant marking.

Certifications & Approvals

Application

The use of our specially formulated adhesive labels printed on thermal transfer printers give the highest quality print clarity. The range of materials are complemented by ribbons developed to suit the needs of most users.
The production of labels is very simple. All that is needed is the required label to be selected from our industry leading software TagPrint Pro.

Colour Red (RD)
Colour Marking Field White (WH)
Fixation Method Pasting / Stick
Mounting method Pasting / Stick
Pack Cont. 1000
Package Quantity per roll
PART DESCRIPTION TAG61-121W254SM-100B-RD
Product Group Adhesive Labels
Type 558-00052
Variant Roller form
With label space Yes
Bundle ∅ max. 11.94mm
Bundle ∅ min. 5.5mm
Core diameter from / to 5.5 - 12.1mm
Height (H) 25.40mm
Height (H2) 57.1mm
HR 25.4mm
HR 1.0"
Outside ∅ max. 0.476"
Outside ∅ max (OD max.) 12.1mm
Outside ∅ min. 0.216"
Outside ∅ min. (OD min.) 5.5mm
Print Method Thermal transfer
Thickness (T) 25µm
Thickness of Foil 35µm
VR 2.62"
VR 66.67mm
Width (W) 25.4mm
Width of Liner (WL) 28.57mm
Width of LIner (WL) 1.125"
Adhesive Acrylic
Adhesive Operating Temperature -40 °C to +150 °C
Curing Temperature from +10 °C
Material Type 100, Vinyl (PVC), white (WH), self-laminating
Operating Temperature - °C -40 °C to +80 °C
Specifications
Specifications UL-Recognized
UL Listed (US and Canada) No
UL OCD link PGJI2.MH18396
PGJI8.MH18396
UL Recognized (US and Canada) Yes
UL-File Number MH18396
EAN / GTIN 4031026299624
Labels per Row 1
Weight 1.6lbs
Weight 0.73kg
ETIM 6.0 EC001530
ETIM 7.0 Key EC001530
UNSPSC Key 39131504
