23/04/2024

Cable label, self laminating, white, laser print, 18.00mm, H2=30.00mm, 1053pcs.
Art.-No. 594-00029 | TAGNL0103018-PBT-WH |  Details

    • Made of Polybutylene Terephthalate (PBT) film
    • White color
    Add to watchlist
    Downloads Datasheet
    Application Can be used as a label format for laser printer. The self-laminated label protects the printed surface from dirt, water, solvents and oils.
    Cable ∅ max 6.7mm
    Colour White (WH)
    Material Polybutylene Terephthalate (PBT)
    Pack Cont. 1053pcs.
    Package Content packed in bag
    Paper Format A4
    PART DESCRIPTION TAGNL0103018-PBT-WH
    Product Family TABTAG Label
    Product Group Label format for laser printer
    H printable 7.00mm
    Height (H2) 30.00mm
    Outside ∅ max (OD max.) 6.70mm
    Print Method laser print
    Thickness (T) 70.0µm
    Width (W) 18.00mm
    Width of Liner (WL) 210.00mm
    Width printable 18.00mm
    Adhesive Acrylic
    Operating Temperature -40 °C to +120 °C
    Specifications
    Specifications ANSI/UL 969
    UL OCD link Link
    UL-File Number MH29199
    Country of Origin JP
    GTIN-13 / EAN 4944387951028
    Labels per Column 9
    Labels per Row 9
    Labels per Sheet 81
    ETIM 7.0 Key EC001530
    ETIM 8.0 Key EC001530
    ETIM 9.0 Key EC001530
