Push-in wire connector, 3 conductors, 0.2 to 4.0 mm² all types of wire, transparent, 500pcs.
Art.-No. 148-90066 | HCRN-3-PC-CL

Copied
HelaCon Releasable HCRN-3.
HelaCon Releasable family.
HelaCon Plus Releasable Box and Blister 2.
HelaCon Releasable HCRN-3 Test.
Push in wire connector HelaCon Releasable HCRN- 3.
HelaCon Releasable HCRN-3.
HelaCon Plus Releasable.

    • Quick release simplifies insertion and removal of wires for fast, safe and secure operation.
    • Connects solid and stranded wires within same housing for versatile wire management.
    • Accepts 12 AWG solid wire and 14 - 28 AWG stranded wire.
    • Clear housing eases inspection with visual verification that wires have been inserted properly.
    Package size
    Add to watchlist
    Downloads
    Application The HelaCon Plus Releasable connectors are used for all types of wire to connect cable and conductors in the field of electrical installation. The connectors can be used in all kinds of junction boxes either on-wall or flush-mounted. HelaCon offers the best possible solution when convenient processing and maximum safety is required.
    Brand Family HelaCon
    Color Clear (CL)
    Description HelaCon Releasable Wire Connectors replace traditional twist-on wire connectors. They provide faster, easier and more reliable connections and distribution of cable and conductors in electrical installation applications. These connectors have a lever action that opens for insertion and repositioning of wires and snaps closed to establish a secure connection. Suitable for use with solid and stranded wires.
    PART DESCRIPTION HCRN-3-PC-CL
    Packaging Type pack
    Part No. 148-90066
    Short Desc. HelaCon Releasable Wire Connector, 3-Port, (Piece & PA66), Clear, 500/pkg
    Type HCRN-3
    Height (imperial) 0.55"
    Height (metric) 14.0mm
    Length (imperial) 0.67"
    Length (metric) 17.0mm
    Max Current 32A
    Max Voltage 450V
    Max. Bundle Diameter (imperial) 0"
    Min. Bundle Diameter (imperial) 0"
    Number of Conductors 3
    Width (imperial) 0.81"
    Width (metric) 20.5mm
    CE Certification Yes
    CSA Certified No
    Flammability UL 94 V-0
    Halogen Free Yes
    Material PC
    Material Polycarbonate (PC)
    Operating Temperature -22°F to +185°F (-30°C to +85°C)
    REACH Conformity Yes
    ROHS compliant Yes
    UL File Number [Logo] E316080 [cULus]
    UL Listed (US and Canada) Yes
    UL Listed (US) Yes
    UL Recognized (US and Canada) No
    UL Recognized (US) No
    Customs Number (Schedule B) 8536908085
    Harmonized Tariff Schedule Code 8536.90.8585
    Pkg. Qty. 500
    Pkg. Qty. 500Pieces
