High Density Slotted Wall Wiring Duct
Art.-No. 184-15206 | SLHD1.5X2-PVC-WH

Copied
Narrow fingers reduce fanning of the wires to the terminal blocks, presenting a neater appearance.

    • Narrow fingers reduce fanning of the wires to the terminal blocks, presenting a neater appearance.
    • Each finger is provided with a double restriction to hold wires in the bottom portion of the duct, allowing for easier installation.
    • Mounting holes are uniform in size and are offered every 2 inches to accommodate compact designs and ease installation.
    • Optional covers snap on and off easily, and are provided with a non-slip lining that insures the covers remain in place during vibration.
    Package size
    Add to watchlist
    Downloads
    Color White (WH)
    Description HellermannTyton High-Density Slotted Wall Wiring Duct features narrow fingers equaling a 2-to-1 finger ratio compared to standard slotted wiring duct. With the narrow fingers, compact designs and components are more easily accommodated.
    PART DESCRIPTION SLHD1.5X2-PVC-WH
    Packaging Type carton
    Part No. 184-15206
    Product family Slotted Wall Wiring Duct
    Short Desc. High Density Slotted Wall Wiring Duct, 1.5" x 2", Non-Adhesive, PVC, White, 120ft/Carton
    Technical Description Non-Adhesive
    Type SLHD1.5X2
    UV Resistant No
    Fixation Method Non-Adhesive
    Height (imperial) 2.07"
    Height (metric) 52.6mm
    Length (imperial) 6.0ft
    Length (metric) 1.83m
    Max. Bundle Diameter (imperial) 0"
    Min. Bundle Diameter (imperial) 0"
    Mounting Hole Centers (imperial) 2.0"
    Width (imperial) 1.5"
    Width (metric) 38.1mm
    Width 2 (imperial) 1.5"
    Width 2 (metric) 38.1mm
    Width 3 (imperial) 0.16"
    Width 3 (metric) 4.1mm
    Width 4 (imperial) 0.4"
    Width 4 (metric) 10.2mm
    Width 5 (imperial) 1.60"
    Width 5 (metric) 40.6mm
    CE Certification Yes
    CSA Certified Yes
    Flammability UL 94 V-0
    Halogen Free No
    Material PVC
    Material Polyvinylchloride (PVC)
    Operating Temperature +122°F (+50°C)
    Prop65 Warning No
    REACH Conformity No
    ROHS compliant Yes
    UL File Number [Logo] E64139 [RU]
    UL Listed (US and Canada) No
    UL Listed (US) No
    UL Recognized (US and Canada) No
    UL Recognized (US) Yes
    Customs Number (Schedule B) 3925900000
    Harmonized Tariff Schedule Code 3925.90.0000
    Pkg. Qty. 120.0ft
    Pkg. Qty. 36.58m

    Wiring ducts and accessories from HelaDuct: optimum protection for cables and fitters.

    Discover the advantages of HelaDuct wiring ducts system solutions with its special space-saving shapes: these unique wiring ducts are designed for height and give you more lateral space. They come with blunted edges that protect the cable insulation and make them safer to work with during installation and maintenance. HelaDuct products are used in switch cabinets and switching stations and are very well suited to cables with small cross sections.
