SLHD2.5X3-PVC-WH : SLHD2.5X3
Art.-No. 181-00233 | SLHD2.5X3-PVC-WH Details

Package size
Colour White (WH)
Material Polyvinylchloride (PVC)
Pack Cont. 9.14m
Package Content packed in box
PART DESCRIPTION SLHD2.5X3-PVC-WH
Fixing Hole Centres (F) 50.8mm
Fixing Hole Centres (F) 2.0"
Height (H) 77.9mm
Length (L) 1.83m
Width (W) 63.5mm
Width (W2) 63.5mm
Width (W3) 4.1mm
Width (W4) 0.4"
Width (W4) 10.2mm
Width (W5) 2.6"
Width (W5) 66.0mm
Width (W6) 19.05mm
Width (W6) 0.75"
CE Certification No
CSA Certified Yes
Halogen-free No
Operating Temperature +50 °C
Self extinguishing Yes
Specifications
Specifications CSA, EN 50085-1:2005 + A1:2013, EN 50085-2-3_1A, UL
UL Listed (US and Canada) No
UL Recognized (US and Canada) Yes
UL-File Number E64139
UV-Stabilised (Yes/No) No
Country of Origin US
Customs Number 3925902000
GTIN-13 / EAN 4031026721460
ETIM 7.0 Key EC000012
ETIM 8.0 Key EC000012
ETIM 9.0 Key EC000012
UNSPSC Key 39131704
