19/09/2026

Cable tie mount for magnetic use, Wmax=5.9mm, white, 10pcs.


Art.-No. 151-04021

| MAGCTM10S-NDFEB35M/POM/ST-WH

 |

Copied
6803396
7615731
7615733
7615732

    Package size
    Add to watchlist
    Downloads e-Learning
    Colour White (WH)
    Fixation Method Magnet
    For Ties T18-T50
    Magnetic pull strength (N) 44N
    Magnetic pull strength (kgf) 4.49
    Magnetic pull strength (lb/ft) 10lbf-ft
    Material Neodymium alloy 35M (NDFEB35M), Polyacetal (POM), Steel (ST)
    PART DESCRIPTION MAGCTM10S-NDFEB35M/POM/ST-WH
    Package Content 10pcs.
    Package Content packed in pack
    Rotation (°) 360°
    Type MAGCTM10S
    ⌀ D 0.75"
    Diameter (D) 19mm
    Height (H) 10.5mm
    Strap Width max. (G) 0.23"
    Strap Width max. (G) 5.9mm
    CE Certification No
    CSA Certified No
    Halogen-free Yes
    Operating Temperature -40 °C to +80 °C
    Plenum Rating AH-2
    ROHS compliant Yes
    Reusable (Yes/No) Yes
    Specifications
    UL Listed (US and Canada) Yes
    UL Listed (US) Yes
    UL Recognized (US and Canada) No
    UL Recognized (US) No
    UL-File Number E64139
    Country of Origin US
    GTIN-13 / EAN 4031026730158
    Packaging 1 - Qty 10
    Packaging 1 - Type pack
    ETIM 7.0 Key EC000449
    ETIM 8.0 Key EC000449
    ETIM 9.0 Key EC000449
    UNSPSC Key 39121703

    Solutions

    Self-Adhesive cable tie mounts Self-Adhesive cable tie mounts

    Self-Adhesive cable tie mounts

    HellermannTyton self-adhesive cable tie mounts are perfectly suited for cable fastening on round and angled surfaces. To save time, reduce part diversity and weight.

    Cable tie mounts
    Art.-No.: 151-04021 Contact
