Cable Tie Mounts with high performance adhesive : MB2APT-A

SolidTack-Series MB, Article number: 151-02243

Features

  • MB mounts with homogeneous system of acrylic adhesive
  • Very good initial adhesion, increases with time
  • Adhesive with high cohesive strength combined with good weathering resistance
  • Innovative fixing solution for high and low energy surfaces
  • Protection foil with finger lift for easy peel off

Certifications & Approvals

Application

SolidTack MB Series mounts have a square design and are fairly common in areas like electrical cabinet, railway, aerospace, automotive and agriculture machinery. The premium self-adhesive bonds well on high and low-energy surfaces like plastics, metal, varnish or paint and is suitable for a wide range of applications.

SolidTack-Series MB is suitable for following markets and industries

Colour Black (BK)
Fixation Method Self-Adhesive
Pack Cont. 100pcs.
Package Quantity per bag
PART DESCRIPTION MB2APT-A-PA66-BK
Product Family SolidTack-Series MB
Product Group Cable Tie Mounts with high performance adhesive
Height (H) 4.1mm
Length (L) 13.0mm
Strap Width max. (G) 2.7mm
Width (W) 13.0mm
Adhesive Acrylate with base of acrylic foam
ELV compliant (Article 4 - 2) YES
Flammability UL 94 V2 (excluding adhesive)
Halogenfree Yes
Hazardous good No
Material Polyamide 6.6 (PA66)
Operating Temperature - °C -40 °C to +85 °C
Specifications
EAN / GTIN 4031026604077
Packaging 1 - Height (m) 0.1m
Packaging 1 - Length (m) 0.22m
Packaging 1 - Qty 100
Packaging 1 - Type bag
Packaging 1 - Volume (m³) 0.00528
Packaging 1 - Weight (kg) 0.05658kg
Packaging 1 - Width (m) 0.24m
Packaging 3 - Height (m) 0.368m
Packaging 3 - Length (m) 0.584m
Packaging 3 - Qty 25000
Packaging 3 - Type carton
Packaging 3 - Volume (m³) 0.083
Packaging 3 - Weight (kg) 14.965kg
Packaging 3 - Width (m) 0.386m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 300000
Packaging 4 - Type pallet
Packaging 4 - Weight (kg) 200.64kg
Packaging 4 - Width (m) 0.8m
Weight 0.0476kg
ETIM 6.0 EC000449
ETIM 7.0 Key EC000449
