Fixing tie for screw fixation, inside serrated, ⌀105.0mm, black, 500pcs.

Art.-No. 156-03055

| T120RCPCM6-SET-PA66HIRHS-BK

|

Base Data

Cable Tie	Polyamide 6.6, heat stabilised (PA66HS)
Colour	Black (BK)
Fixation Method	Screw Mount
Identification Plate Position	none
Material	Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
Min.Tensile Strength	535N
Mounting Screw Type	M6 Screw
PART DESCRIPTION	T120RCPCM6-SET-PA66HIRHS-BK
Package Content	500pcs.
Package Content packed in	pack
Releasable Closure (Yes/No)	No
Tie Closure	plastic pawl
Type	T120RCPCM6-SET
Variant	Inside Serrated

Product Dimensions

Bundle ⌀	105.0mm
Bundle ⌀ max.	105.0mm
Height (H)	16.0mm
Length (L)	390.0mm
Stud ⌀	0.24"
Width (W)	7.6mm
for Hole ⌀ (FH)	6.2 mm

Downloads

Specifications

CE Certification	No
CSA Certified	No
Operating Temperature	-40 °C to +105 °C
ROHS compliant	Yes
Specifications

Logistics and Packaging


Country of Origin	CN
GTIN-13 / EAN	4031026647180
Packaging 1 - Qty	500
Packaging 1 - Type	bag
Packaging 3 - Height (m)	0.1397m
Packaging 3 - Length (m)	0.51276m
Packaging 3 - Type	box
Packaging 3 - Volume (m³)	0.0223m³
Packaging 3 - Width (m)	0.31115m

More Information

ETIM 7.0 Key	EC000046
ETIM 8.0 Key	EC000046
ETIM 9.0 Key	EC000046
UNSPSC Key	39121703
