Cable Ties inside serrated : T50R

Article number: 111-01564

Features

  • Available in a wide range of materials and sizes
  • High tensile strength with very low insertion force
  • Only high quality plastic is used meeting recycling targets
  • Inside serrated cable ties for a strong hold onto bundles
  • Ergonomic bent tail offers quick and simple installation
  • Easy application either manually or with an application tool

Certifications & Approvals

Application

T-Series cable ties for bundling and securing of cables, pipes and hoses. These cable ties can be used for nearly all kind of applications.

Application Tool MK3PNSP2, MK3SP, MK6, MK7HT, MK7P, MK20, MK21, EVO7, EVO9
Colour Black (BK)
Identification Plate Position none
Pack Cont. 1000pcs.
Package Quantity per bag
PART DESCRIPTION T50R-PA12-BK
Product Group Cable Ties inside serrated
Releasable Closure (Yes/No) No
Tie Closure plastic pawl
Variant Inside Serrated
Bundle ∅ max. 50.0mm
Bundle ∅ min. 3.3mm
Length (L) 203.2mm
Min.Tensile Strength 200.0N
Thickness (T) 1.2mm
Width (W) 4.6mm
CSA Certified No
Flammability UL 94 HB
Material Polyamide 12 (PA12)
Operating Temperature - °C -40 °C to +95 °C
Specifications
UL Listed (US and Canada) No
UL Recognized (US and Canada) No
EAN / GTIN 4031026465067
ETIM 6.0 EC000046
ETIM 7.0 Key EC000046
UNSPSC Key 39121703
