Fixing tie for hole (round), outside serrated, ∅3.0-30.0mm, black, 100pcs.
Art.-No. 126-00057 | OS160FT5-PA66HSUV-BK Details

  • Cable tie head always situated in defined position
  • Easy to assemble without the need for a tool
  • Disc adjusts tie for pressure from various directions and minimises ingress of dust and dirt
  • Fir tree foot part can be used for a variety of panel thicknesses
  • Suitable for use within threaded holes
  • Parts with an anti-slip engraving, such as the T30SOS-AS-FT5-E, to prevent the harness from slipping sideways
Show more
Application Primarily designed for fixing cable harnesses in the automotive industry, their simplicity and ease of use has resulted in these parts being used in other industries, for example aviation, switch gear manufacturer, white goods manufacturer.
Colour Black (BK)
Fixation Method Fir tree for round holes
Identification Plate Position none
Material Polyamide 6.6, heat and UV-stabilised (PA66HSUV)
PART DESCRIPTION OS160FT5-PA66HSUV-BK
Pack Cont. 100pcs.
Package Content packed in bag
Product Family Fir tree parts FT5
Product Group 1-piece fixing ties with fir tree, with disc, for round holes
Releasable Closure (Yes/No) No
Tie Closure plastic pawl
Type OS160FT5
Bundle Diameter max (metric) 30.0mm
Bundle ∅ 3.0-30.0mm
Bundle ∅ min. 3.0mm
Disc ∅ 13.0mm
Hole Depth 5.6mm
Length (L) 163.0mm
Length (L2) 11.40mm
Min.Tensile Strength 100N
Thickness (T) 1.4mm
Weight/Unit 0.00107kg
Width (W) 4.0mm
Width (W2) 5.4mm
for Hole ∅ (FH) 4.5 - 5.0 mm
for Panel Thickness min - max 1.6 - 3.2 mm
ELV compliant (Article 4 - 2) YES
Flammability UL 94 V2
Hazardous Goods No
Operating Temperature -40 °C to +110 °C
ROHS compliant Yes
Specifications
Country of Origin JP
Customs Number 39269097
GTIN-13 / EAN 4944387948356
Packaging 1 - Qty 100
Packaging 1 - Type bag
Packaging 1 - Weight (kg) 0.107001kg
Packaging 3 - Height (m) 0.315m
Packaging 3 - Length (m) 0.505m
Packaging 3 - Qty 2500
Packaging 3 - Type box
Packaging 3 - Volume (m³) 0.0589
Packaging 3 - Weight (kg) 3.205025kg
Packaging 3 - Width (m) 0.37m
Packaging 4 - Height (m) 1.089m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 30000
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 1.045
Packaging 4 - Weight (kg) 59.46kg
Packaging 4 - Width (m) 0.8m
ETIM 7.0 Key EC000046
ETIM 8.0 Key EC000046
ETIM 9.0 Key EC000046
UNSPSC Key 39121703
