Fixing tie for edge, outside serrated, ⌀1.0-45.0mm, black, 500pcs.
Art.-No. 156-03582 | S50ROSEC22-PP/PA66HIRHS-BK

Pre-assembled 2-piece fixing tie with EdgeClip
Cable tie head can be moved after bundling
The S50ROS features a significantly lower CO₂ footprint compared to cable ties made of standard material, in line with sustainability goals in various industries
The outside serration design ensures gentle handling of sensitive cables and bundles, reducing the risk of damage during installation and maintenance
With an anti-slip feature on the inside, the S50ROS prevents undesired lateral movement of cables and bundles, maintaining tidy and organized cable management within vehicles
For edges of 1 – 3 mm

More products in this product group:

Application	S-Series cable ties made from Polypropylene (PP) are non hydroscopic, offer a higher chemical resistance and reduced CO2 footprint compared to a standard cable tie material. These cable ties are used to bundle and secure cables, pipes and/or hoses.
Brand Family	EC-Series
Color	Black (BK)
Description	HellermannTyton's Two-Piece Edge Clip with Cable Tie assemblies are designed specifically to route bundles by securing them to the edge of a plastic or metal sheet without the need for a mounting hole. The clip is easy to secure, and the pull-off strength is high due to the integrated metal clamp that holds the edge clip in place.
Key product features	for narrow bundling, small diameter
Min. Tensile Strength (metric)	185N
PART DESCRIPTION	S50ROSEC22-PP/PA66HIRHS-BK
Packaging Type	bag
Part No.	156-03582
Product family	2-Piece Tie Assemblies
Product family	Edge fixation products
Type	S50ROSEC22

Cable Tie Closure	plastic pawl
Fixation Method	EdgeClip, sideway, assembled, 2 piece
Height (metric)	1.45mm
Height 2 (metric)	12.5mm
Identification Plate Position	none
Length (metric)	200.00mm
Length 2 (metric)	15.0mm
Max. Bundle Diameter (metric)	45.0mm
Max. Panel Thickness (metric)	3.0mm
Min. Bundle Diameter (metric)	1.0mm
Min. Panel Thickness (metric)	1.0mm
Panel Thickness (metric)	1.0 - 3.0mm
Releasable Closure	No
Thickness (metric)	1.45mm
Width (metric)	4.90mm
Width 2 (metric)	9.2mm

Cable Tie	Polypropylene (PP)
Material	PP, PA66HIRHS
Material	Polypropylene (PP), Polyamide 6.6, high impact modified, heat stabilized (PA66HIRHS)
Material Foot Part	PA66HIRHS
Operating Temperature	-40°F to +230°F (-40 °C to +110 °C), (3000 h)
REACH Conformity	Yes
ROHS compliant	Yes
