Fixing tie for edge, inside serrated, ⌀1.5-45.0mm, black, 5000Set
Art.-No. 156-00263 | T50RATSEC38SET-PA66HS/PA66HIRHS-BK

Copied
Edge Clip 10 (EC10) fitted onto a plastic panel to hold a ⌀ 6 mm harness.

    Add to watchlist
    Downloads
    Color Black (BK)
    Content 5000 T50R + 5000 ATSEC38
    Min. Tensile Strength (metric) 225N
    PART DESCRIPTION T50RATSEC38SET-PA66HS/PA66HIRHS-BK
    Packaging Type box
    Part No. 156-00263
    Product family 2-Piece Tie Assemblies
    Product family Edge fixation products
    Type T50RATSEC38SET
    Cable Tie Closure plastic pawl
    Fixation Method Edge Clip
    Height (metric) 1.2mm
    Height 2 (metric) 14.5mm
    Identification Plate Position none
    Length (metric) 200.0mm
    Length 2 (metric) 15.0mm
    Max. Bundle Diameter (metric) 45.0mm
    Max. Panel Thickness (metric) 4.0mm
    Min. Bundle Diameter (metric) 1.5mm
    Min. Panel Thickness (metric) 1.5mm
    Releasable Closure No
    Width (metric) 4.6mm
    Width 2 (metric) 16.4mm
    Halogen Free Yes
    Material PA66HS, PA66HIRHS
    Material Polyamide 6.6 heat stabilized (PA66HS), Polyamide 6.6, high impact modified, heat stabilized (PA66HIRHS)
    REACH Conformity Yes
    ROHS compliant Yes
    Pkg. Qty. 5000Set
    Show all
    Cable holder Cable holder

    Cable holder

    Looking for a secure way to fasten cables or wires? Our plastic cable holders are easy to install and suitable for almost any application. Learn more...

    Cable holder >
    Art.-No.: 156-00263 Contact
    Base Data Product Dimensions Material and Specifications Logistic and Packaging Downloads
