Fixing tie for hole (round), black, 500pcs.
Art.-No. 156-01550 | T50RFT6SD-PA66HS/PA66HIRHS-BK

Copied
These fir tree fixings can also be used in threaded, blind holes.
Fir tree mounts with cable ties provide a secure grip in mounting holes and protect against dirt and other impurities.

    • Friction tab inside the fir tree allows the tie to sit in mount without falling out prior to installation.
    • Fir tree provides low insertion effort yet demonstrates high extraction resistance.
    • Disc feature prevents rattling in high-vibration applications and protects against debris ingress.
    Package size
    Add to watchlist
    Downloads e-Learning
    Application Primarily designed for fixing cable harnesses in the automotive industry their simplicity, and ease of use, has seen these parts used in everything from aircraft, to switch-gear, to washing machines.
    Color Black (BK)
    Description HellermannTyton’s fir tree mounts provide a secure grip in a mounting hole. The mount can slide along the cable tie to adjust orientation as needed. Fir tree mounts are designed to provide a low insertion force and high extraction force. This mount is sold as an assembly with the cable tie.
    PART DESCRIPTION T50RFT6SD-PA66HS/PA66HIRHS-BK
    Packaging Type bag
    Part No. 156-01550
    Product family 2-Piece Tie Assemblies
    Product family Fixing ties for holes
    Type T50RFT6SD
    Cable Tie Closure plastic pawl
    Fixation Method Fir Tree
    Identification Plate Position none
    Mounting Hole Diameter (metric) 6.4 - 7.1 mm
    Material PA66HS, PA66HIRHS
    Material Polyamide 6.6 heat stabilized (PA66HS), Polyamide 6.6, high impact modified, heat stabilized (PA66HIRHS)
    ROHS compliant Yes
    Pkg. Qty. 500Pieces
    Cable holder Cable holder

    Cable holder

    Looking for a secure way to fasten cables or wires? Our plastic cable holders are easy to install and suitable for almost any application. Learn more...

    Cable holder >
    Art.-No.: 156-01550 Contact
