2-Piece Fixing Ties with Arrowhead, with Disc for high temperature applications T50ROSP2SFT6.5

T50ROSP2SFT6.5 for panel thickness 1.7 - 2.3 mm, Article number: 156-00456

Features

  • Pre-assembled 2-piece fixing tie with arrowhead foot part
  • Cable tie head can be moved after bundling
  • Easy to assemble without the need for a tool
  • Arrowhead simply locks into place
  • Disc adjusts tie for pressure from various directions and minimises access of dust, dirt and water
  • Features material PEEK:
  • '-55 °C to +240 °C operating temperature
  • Excellent resistance against chemicals and gamma radiation

Certifications & Approvals

Application

The Fixing-Ties with P1SFT6.5 and P2SFT6.5 are ideal when the requirements for temperature or chemical resistance are very high. They are used for cable harnesses in the automotive industry.

T50ROSP2SFT6.5 for panel thickness 1.7 - 2.3 mm is suitable for following markets and industries

Application Tool MK3PNSP2, MK3SP, MK7HT, MK7P, MK20, EVO7
Colour Grey (GY), Beige (BGE)
Fixation Method Arrowhead
Fixing Hole Shape Circular
GLOBAL PART DESCRIPTION T50ROSP2SFT6.5-PA46/PEEK-GY/BGE
Identification Plate Position none
Pack Cont. 100pcs.
Package Quantity per bag
Product Family T50ROSP2SFT6.5 for panel thickness 1.7 - 2.3 mm
Product Group 2-Piece Fixing Ties with Arrowhead, with Disc for high temperature applications
Tie Closure plastic pawl
Variant Outside Serrated
Bundle ∅ max. 45.0mm
Bundle ∅ min. 1.0mm
Disc ∅ 16.0mm
for Hole ∅ (FH) 6.3 - 6.7 mm
for Panel Thickness min - max 1.7 - 2.3 mm
for Panel Thickness min - max 0.1 - 0.1 "
Height (H) 16.0mm
Height (H2) 16mm
Length (L) 200.0mm
Length (L2) 8.6mm
Min.Tensile Strength 225.0N
Panel Thickness max. 1.7 – 2.3mm
Thickness (T) 1.3mm
Width (W) 4.6mm
Cable Tie Polyamide 4.6 (PA46)
ELV compliant (Article 4 - 2) YES
Flammability UL 94 V2, UL 94 V0
Foot Part Polyetheretherketone (PEEK)
Hazardous good No
Material Polyamide 4.6 (PA46), Polyetheretherketone (PEEK)
Operating Temperature - °C -40 °C to +150 °C, -55 °C to +240 °C
Specifications
UL Listed (US and Canada) No
UL Recognized (US and Canada) No
EAN / GTIN 4031026300160
Packaging 1 - Height (m) 0.15m
Packaging 1 - Length (m) 0.3m
Packaging 1 - Qty 100
Packaging 1 - Type bag
Packaging 1 - Volume (m³) 0.0117
Packaging 1 - Weight (kg) 0.1744kg
Packaging 1 - Width (m) 0.26m
Packaging 3 - Height (m) 0.204m
Packaging 3 - Length (m) 0.591m
Packaging 3 - Qty 2000
Packaging 3 - Type carton
Packaging 3 - Volume (m³) 0.048
Packaging 3 - Weight (kg) 4.138kg
Packaging 3 - Width (m) 0.398m
Packaging 4 - Height (m) 1.164m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 40000
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 1.117
Packaging 4 - Weight (kg) 103.6kg
Packaging 4 - Width (m) 0.8m
Weight 0.16kg
ETIM 6.0 EC000046
UNSPSC Key 39121703
