Fixing tie for stud, inside serrated, ⌀45.0mm, natural/black, 500pcs.
Art.-No. 156-00758 | T50RSBH5-10-PA66HS/PA66HIRHS-NA/BK

Copied

    • Versatile design allows cable routing above, perpendicular or parallel to stud.
    • Can mount up to three bundles simultaneously, making efficient use of a single mounting point.
    • Four-pawl, three-tooth design delivers outstanding stud retention to keep bundles secure.
    • PA46 material option allows use in high-heat applications.
    Add to watchlist
    Downloads e-Learning
    Application Primarily designed for use in the automotive industry, these parts can be used in a wide variety of applications where 5mm weld studs or 5mm ISO bolts are used and cables need to be bundled and secured
    Color Natural (NA), Black (BK)
    Description Unique, two-piece design allows routing to be above, parallel or perpendicular to stud. This also enables up to three separate bundles to be fastened to the same stud. With their low insertion force and high extraction performance, HellermannTyton mounting ties offer the ideal combination of high-grade materials and superior design to suit the mounting and bundling needs of complex applications. Available in standard and high-heat material options.
    PART DESCRIPTION T50RSBH5-10-PA66HS/PA66HIRHS-NA/BK
    Packaging Type bag
    Part No. 156-00758
    Product family Stud Mounts
    Product family Products to use on studs
    Type T50RSBH5-10
    Cable Tie Closure plastic pawl
    Disc Diameter (metric) 25.0mm
    Fixation Method Weld Stud Fixing
    Height 2 (metric) 26.0mm
    Identification Plate Position none
    Length (metric) 200.0mm
    Max. Bundle Diameter (metric) 45.0mm
    Stud Diameter (metric) 5.0 mm
    Thickness (metric) 1.2mm
    Width (metric) 4.6mm
    Width 2 (metric) 28.0mm
    Width 3 (metric) 10.0mm
    Material PA66HS, PA66HIRHS
    Material Polyamide 6.6 heat stabilized (PA66HS), Polyamide 6.6, high impact modified, heat stabilized (PA66HIRHS)
    ROHS compliant Yes
    Pkg. Qty. 500Pieces
