29/03/2024

Fixing tie for hole (round), inside serrated, Ø50.0mm, black, 1000pcs.
Art.-No. 126-00034 | T50RSF6.5F-PA66HIRHS-BK Details

  • Easy to install without the need for a tool
  • Arrowhead simply locks into place
  • Disc adjusts tie for pressures from various directions and minimises ingress of dust and dirt
  • Cable tie head always situated in a defined position
  • KSFT-types with specially rounded arrowhead minimise the assembly height
Show more
Application With a diverse range of fixing possibilities these ties are ideal for use in many different industries, including automotive, aerospace, white goods manufacture and panel building. This fastening solution is used to secure cable harnesses. We offer a variety of panel thicknesses and hole sizes to suit all kinds of application.
Application Tool MK3PNSP2, MK7P, EVO7, EVO7SP, EVO7i, EVO9, EVO9SP
Colour Black (BK)
Fixation Method arrowhead
Identification Plate Position none
Material Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
Pack Cont. 1000pcs.
Package Content packed in pcs.
PART DESCRIPTION T50RSF6.5F-PA66HIRHS-BK
Product Family for round holes
Product Group 1-piece fixing ties with arrowhead, with disc
Releasable Closure (Yes/No) No
Tie Closure plastic pawl
Variant Inside Serrated
Bundle Diameter max (metric) 50.0mm
Bundle ∅ 50.0mm
for Hole ∅ (FH) 6.1 - 6.5 mm
for Panel Thickness min - max 0.6 - 3 mm
for Panel Thickness min - max 0 - 0.2 "
Length (L) 210mm
Thickness (T) 1.3mm
Weight/Unit 0.002018kg
ELV compliant (Article 4 - 2) YES
Hazardous Goods No
Specifications
Country of Origin FR
Customs Number 39269097
GTIN-13 / EAN 4031026254555
Packaging 1 - Height (m) 0.2m
Packaging 1 - Length (m) 0.47m
Packaging 1 - Qty 1000
Packaging 1 - Type bag
Packaging 1 - Volume (m³) 0.05123
Packaging 1 - Weight (kg) 2.038kg
Packaging 1 - Width (m) 0.545m
Packaging 3 - Height (m) 0.538m
Packaging 3 - Length (m) 0.584m
Packaging 3 - Qty 4000
Packaging 3 - Type box
Packaging 3 - Volume (m³) 0.1213
Packaging 3 - Weight (kg) 9.252kg
Packaging 3 - Width (m) 0.386m
Packaging 4 - Height (m) 1.22m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 32000
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 1.171
Packaging 4 - Weight (kg) 95.016kg
Packaging 4 - Width (m) 0.8m
ETIM 7.0 Key EC000046
ETIM 8.0 Key EC000046
ETIM 9.0 Key EC000046
UNSPSC Key 39121717
