Bundling clip for hole (round), L=27.3mm, black, 20000pcs.
Art.-No. 151-02226
| BCOWFT6M-PA66HIRHS-BK
Copied
- simple installation, tool-free - "single-leaf" winding beam, saves weight and space - anti-twist protection, due to the base section geometry
More products in this product group:
| Application |
This product was specially developed for the automotive industry, but it is also is also used wherever cables are routed and assembled with a winding bar. are guided and assembled. The comparative article with the option of winding to the right and left of the foot section is the TCOP62x122. |
| Color | Black (BK) |
| Description | HellermannTyton connector clips, for oval holes, are mounted simply by pushing them onto the corresponding clip. The clips provide a wide range of mounting options with anti-rattle and anti-rotation features. The fir tree locks into place when inserted into the hole palpably and ensures a secure fixing at all times. |
| PART DESCRIPTION | BCOWFT6M-PA66HIRHS-BK |
| Packaging Type | box |
| Part No. | 151-02226 |
| Product family | Bundling Clips |
| Product family | Bundling Clips |
| Type | BCOWFT6M |
| Fixation Method | Plug-in mounting |
| Height (metric) | 11.6mm |
| Height 2 (metric) | 21.3mm |
| Length (imperial) | 1.46" |
| Length (metric) | 27.3mm |
| Max. Mounting Hole Diameter (imperial) | 0.28" |
| Max. Panel Thickness (imperial) | 0.14" |
| Max. Panel Thickness (metric) | 3.5mm |
| Min. Mounting Hole Diameter (imperial) | 0.26" |
| Min. Panel Thickness (imperial) | 0.02" |
| Min. Panel Thickness (metric) | 0.6mm |
| Mounting Hole Diameter (imperial) | 0.26 - 0.28 " |
| Mounting Hole Diameter (metric) | 6.5 - 7.0 mm |
| Mounting Hole Shape | Round |
| Panel Thickness (metric) | 0.6 - 3.5mm |
| Tape Bar Length (metric) | 27.3mm |
| Width (metric) | 8.0mm |
