04/10/2026

Connector clip, black, 1000pcs.


Art.-No. 151-02563

| CC4AHOVAL7X12-PA66HIRHSUV-BK

 |

Copied
1891963

    • Connector clips provide a single method to mount connectors to various surfaces in a variety of applications.
    • Highly engineered designs feature anti-rattle discs, anti-rotation oval fir trees and clamps for mounting on edges.
    • A wide assortment of styles is available to fit the variety of connector slot designs made by most of the largest global connector manufacturers.
    Add to watchlist
    Downloads
    Colour Black (BK)
    Fixation Method Arrowhead for oval holes
    Material Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV)
    PART DESCRIPTION CC4AHOVAL7X12-PA66HIRHSUV-BK
    Package Content 1000pcs.
    Package Content packed in bag
    Type CC4AHOVAL7X12
    Typical Application The Connector Clips used here have been designed for electronic cables and cable sets used in the automotive industry. These parts are related to a connector and then secured to a surface depending on the requirement
    UV-Stabilised Yes
    Height (H) 16.0mm
    Length (L) 30.1mm
    Panel Thickness 1.4 - 1.6mm
    Width (W) 16.0mm
    for Hole ⌀ (FH) 7.0 x 12.0 mm
    for Panel Thickness min - max 1.4 - 1.6 mm
    Operating Temperature -40 °C to +105 °C
    UL Listed (US and Canada) No
    UL Listed (US) No
    UL Recognized (US and Canada) No
    UL Recognized (US) No
    Country of Origin MX
    GTIN-13 / EAN 4031026794457
    Packaging 3 - Height (m) 0.1730375m
    Packaging 3 - Length (m) 0.57785m
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.0349m³
    Packaging 3 - Width (m) 0.34925m
    ETIM 7.0 Key EC000127
    ETIM 8.0 Key EC000127
    ETIM 9.0 Key EC000127
    UNSPSC Key 31162305
