21/05/2024

Connector clip for hole (oval), black, 3500pcs.
Art.-No. 151-03152 | CCOVAL12.5SO-PA66HIRHSUV-BK |  Details

    Add to watchlist
    Downloads
    Colour Black (BK)
    Material Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV)
    PART DESCRIPTION CCOVAL12.5SO-PA66HIRHSUV-BK
    Pack Cont. 3500pcs.
    Package Content packed in box
    Type CCOVAL12.5SO
    Height (H) 26.0mm
    Length (L) 24.9mm
    Weight/Unit 0.00155kg
    Width (W) 17.6mm
    for Hole ∅ (FH) 6.2 x 12.2 mm, 6.5 x 12.5 mm, 6.5 x 13.0 mm, 7.0 x 12.0 mm
    for Panel Thickness min - max 0.6 - 6.8 mm
    ELV compliant (Article 4 - 2) YES
    Hazardous Goods No
    Operating Temperature -40 °C to +105 °C
    ROHS compliant Yes
    Specifications
    UL Listed (US and Canada) No
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) No
    UL Recognized (US and Canada) No
    UV-Stabilised Yes
    Country of Origin US
    Customs Number 39269097
    GTIN-13 / EAN 4031026635118
    Packaging 1 - Height (m) 0.202m
    Packaging 1 - Length (m) 0.51m
    Packaging 1 - Qty 3500
    Packaging 1 - Type bag
    Packaging 1 - Volume (m³) 0.03194m³
    Packaging 1 - Weight (kg) 5.425001kg
    Packaging 1 - Width (m) 0.31m
    Packaging 3 - Height (m) 0.20954999999999998m
    Packaging 3 - Length (m) 0.517525m
    Packaging 3 - Qty 3500
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.0344m³
    Packaging 3 - Weight (kg) 6.035001kg
    Packaging 3 - Width (m) 0.3175m
    Packaging 4 - Height (m) 1.194m
    Packaging 4 - Length (m) 1.2m
    Packaging 4 - Qty 70000
    Packaging 4 - Type pallet
    Packaging 4 - Volume (m³) 1.146m³
    Packaging 4 - Weight (kg) 141.7kg
    Packaging 4 - Width (m) 0.8m
    ETIM 7.0 Key EC000127
    ETIM 8.0 Key EC000127
    ETIM 9.0 Key EC000127
    UNSPSC Key 39121702
