Bundling clip, L=65.4mm, black, 1000Bag
Art.-No. 133-03397 | SOCSB5-PA66HIRHSUV-BK |

Copied

    Add to watchlist
    Downloads
    Application Bundling clips are designed to provide simple and easy methods of securing cable bundles, hoses, or pipes. They are fastened onto the tape bar using bundle or cable ties. The different fixing orientations allow tape clips to be used with a wide range of panel thicknesses and hole diameters. Standard bundling clips are available as well as standoff and stud mount versions.
    Colour Black (BK)
    Material Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV)
    PART DESCRIPTION SOCSB5-PA66HIRHSUV-BK
    Package Content 1000Bag
    Package Content packed in bag
    Type SOCSB5
    Bundling Bar Length 2.57"
    Bundling Bar Length 65.4mm
    Height (H) 17.5mm
    Length (L) 65.4mm
    Stud ⌀ 0.20"
    Stud ⌀ 5.0 mm
    Width (W) 34.8mm
    for Hole ⌀ (FH) 5.0 mm
    CE Certification No
    CSA Certified No
    Flammability UL 94 HB
    Operating Temperature -40 °C to +105 °C
    ROHS compliant Yes
    Specifications
    UL Listed (US and Canada) No
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) No
    UL Recognized (US) No
    Country of Origin US
    GTIN-13 / EAN 4031026594767
    Packaging 1 - Type bag
    Packaging 3 - Height (m) 0.1397m
    Packaging 3 - Length (m) 0.51276m
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.0223m³
    Packaging 3 - Width (m) 0.31115m
    ETIM 7.0 Key EC000127
    ETIM 8.0 Key EC000127
    ETIM 9.0 Key EC000127
    UNSPSC Key 39121702
