23/02/2026

T-Shapes, VG style
Art.-No. 412-07015 | 1207-1-J-PO-X-BK

Copied
a: Expanded form (supplied)
b: Fully recovered form (after heating)

    • 4-way outlet shape
    • Cable sealing, strain relief and mechanical protection
    Add to watchlist
    Downloads
    Application Heat Shrinkable moulded shapes for use in Electrical and Electronic Cable Harness Applications.
    Brand Family HELASHRINK
    Color Black (BK)
    Description Helashrink 1200 series, VG style, provides strain relief, sealing and mechanical protection on cable harnesses.
    PART DESCRIPTION 1207-1-J-PO-X-BK
    Packaging Type bag
    Part No. 412-07015
    Product family Insulation
    Short Desc. Heat Shrink Molded Shapes, 1200 Series T - VG, 1207-1-J, PO-X, BK, 1/bag
    Type 1207-1-J
    UV Resistant No
    ⌀H max. b 12.4mm
    ⌀H min. a 26.9mm
    ⌀J max. b 12.4mm
    ⌀J min. a 26.9mm
    ⌀K max. b 12.4mm
    ⌀K min. a 26.9mm
    Flexibility Semi rigid
    For Object Outside Diameter 15.3-24 mm
    HW ± 20 % 2.5mm
    HW ± 20% .1"
    JW ± 20 % 2.5mm
    JW ± 20% .1"
    Max. Bundle Diameter (imperial) 0"
    Max. Diameter J b .48"
    Max. Diameter K b .48"
    Max. Recovered Diameter b .48"
    Min. Bundle Diameter (imperial) 0"
    Min. Diameter J a 1.05"
    Min. Diameter K a 1.05"
    Min. Supplied Diameter a 1.05"
    P ± 10 % 120.1mm
    P ± 10% 4.68"
    Dielectric Strength 14kV/mm
    Dielectric Strength test method ASTM D2671
    Flammability ASTM D635
    Material PO-X
    Material Polyolefin, cross-linked (PO-X)
    Min. Shrink Temperature +275 °F (+135 °C)
    Operating Temperature -103°F to +302°F (-75°C to +150°C)
    ROHS compliant Yes
    Packaging 1 - Weight (kg) 0.027001kg
    Pkg. Qty. 1
    Pkg. Qty. 1EA

    Heat shrink end caps

    Heat shrink end cap >
