Label, weather resistant/chemical resistance, black, thermal transfer print, 45.70x45.7mm, 500pcs.
Art.-No. 596-00403
| NPLH46X46BK30.5-PET-BK
Copied
- Foam Nameplate labels are less costly than plastic or metal engraved plates, saving material costs.
- Foam Nameplate labels conform to textured and other low energy surfaces ensuring the labels stay in place for the life of the product.
- Labels are UV and chemical resistant for long life in an industrial environment.
- Foam nameplate labels are printable using a thermal transfer printer for complete control and on-demand creation of labels.
More products in this product group:
| Application |
The use of our specially formulated adhesive labels printed on thermal transfer printers give the highest quality print clarity. The range of materials are complemented by ribbons developed to suit the needs of most users. The production of labels is very simple. All that is needed is the required label to be selected from our industry leading software TagPrint Pro. |
| Brand Family | NPLH-Series |
| Color | Black (BK) |
| Description | Foam Nameplate labels are designed to replace plastic and metal engraved phenolic plates commonly found on electrical control panels. The labels provide the look and feel of a plastic engraved or metal plate, but at a fraction of the cost. Labels can be printed using HellermannTyton Tagprint Pro labeling software and can include printed logos, barcodes and text of almost any size and type. |
| Key product features | weather resistant, chemical resistance |
| PART DESCRIPTION | NPLH46X46BK30.5-PET-BK |
| Packaging Type | pack |
| Part No. | 596-00403 |
| Print Method | thermal transfer print |
| Short Desc. | Foam Nameplate, 1.8" x 1.8" Button Label With 1.8" Hole, PET, Black, 500/roll |
| Technical Description | Foam Nameplate, 1.8" X 1.8" Button Label With 1.8" Hole, PET, Black |
| Type | NPLH46X46BK30.5 |
| UV Resistant | No |
|
|
|
| Height (imperial) | 1.80" |
| Height (metric) | 45.70mm |
| Horizontal Repeat (imperial) | 1.80" |
| Horizontal Repeat (metric) | 45.70mm |
| Liner Width (imperial) | 2.0" |
| Liner Width (metric) | 50.8mm |
| Max. Bundle Diameter (imperial) | 0" |
| Min. Bundle Diameter (imperial) | 0" |
| Self adhesive (Yes/No) | Yes |
| Vertical Repeat (imperial) | 2.0" |
| Vertical Repeat (metric) | 50.8mm |
| Width (imperial) | 1.8" |
| Width (metric) | 45.7mm |
Download
| Adhesive | Acrylate with base of acrylic foam |
| Adhesive Operating Temperature | -40°F to +176°F (-40°C to +80°C) |
| CE Certification | No |
| CSA Certified | No |
| Halogen Free | No |
| Material | PET |
| Material | Polyester (PET) |
| Operating Temperature | -40°F to +300°F (-40°C to +149°C) |
| Pre-Printed | No |
| Prop65 Warning | No |
| REACH Conformity | Yes |
| ROHS compliant | Yes |
| UL Listed (US and Canada) | No |
| UL Listed (US) | No |
| UL Recognized (US and Canada) | No |
| UL Recognized (US) | No |
