Label, weather resistant/chemical resistance, white, thermal transfer print, 30.98x69.85mm, 3000pcs.
Art.-No. 596-42822 | TAG72T1-822-WH

Copied
  • Very clear and detailed image for use with graphics, single or sequential characters and especially barcodes
  • Smear-resistant, ultraviolet-resistant and chemical-resistant marking
Application Telecommunications Space (For Flat Surfaces Only)
Colour White (WH)
Key product features weather resistant, chemical resistance
Material Type 822, Polyester (822)
PART DESCRIPTION TAG72T1-822-WH
Pack Cont. 3000pcs.
Package Content packed in pack
Product Family Thermal Transfer Labels
Product Group Adhesive Labels
Self adhesive (Yes/No) Yes
Type TAG72T1
H printable 30.98mm
HR 69.85mm
HR 2.75"
Height (H) 30.98mm
Print Method thermal transfer print
Thickness (T) 64.0µm
UV-Stabilised No
VR 34.93mm
VR 1.375"
Width (W) 69.85mm
Width of LIner (WL) 2.95"
Width of Liner (WL) 74.95mm
Adhesive Acrylic
Adhesive Operating Temperature -73 °C to +178 °C
CE Certification No
CSA Certified No
Curing Temperature +10 °C
Halogen-free Yes
Operating Temperature -40 °C to +150 °C
Pre-Printed No
ROHS compliant Yes
Specifications
Specifications UL-Recognized
UL Listed (US and Canada) No
UL Listed (US and Canada) No
UL OCD link Link Link
UL Recognized (US and Canada) Yes
UL Recognized (US) Yes
UL-File Number MH18396
Country of Origin US
GTIN-13 / EAN 4031026727080
Labels per Column 1
Labels per Row 1
Packaging 1 - Type roll
Packaging 1 - Weight (kg) 0.68kg
ETIM 7.0 Key EC001288
ETIM 8.0 Key EC001288
ETIM 9.0 Key EC001288
UNSPSC Key 55121612
