Adhesive Labels : TAG73T1
Thermal Transfer Labels, Article number: 596-73822
Features
The thermal transfer print guarantees a very clear and detailed image for use with graphics, single or sequential characters and especially barcodes. Helatag® labels offer the choice for smear-resistant, ultraviolet-resistant and chemical-resistant marking.
Certifications & Approvals
Application
White Polyester Splice Enclosure Label. Ladder Rack / Conduit / Busbar (For Flat Surfaces Only)
More products in this product group
Adhesive Labels >| Colour | White (WH) |
| Pack Cont. | 3000pcs. |
| Package Quantity per | roll |
| PART DESCRIPTION | TAG73T1-822-WH |
| Product Family | Thermal Transfer Labels |
| Product Group | Adhesive Labels |
|
|
| H printable | 25.4mm |
| Height (H) | 25.4mm |
| HR | 50.8mm |
| HR | 2.0" |
| Print Method | Thermal transfer |
| Thickness (T) | 64.0µm |
| VR | 1.125" |
| VR | 28.57mm |
| Width (W) | 50.8mm |
| Width of LIner (WL) | 2.20" |
| Width of Liner (WL) | 55.83mm |
| Adhesive | Acrylic |
| Adhesive Operating Temperature | -40 °C to +120 °C |
| CSA Certified | No |
| Curing Temperature | +10 °C |
| Halogenfree | No |
| Material | Type 822, Polyester (822) |
| Operating Temperature - °C | -40 °C to +150 °C |
| Specifications |
|
| Specifications | UL-Recognized |
| UL Listed (US and Canada) | No |
| UL OCD link |
PGJI2.MH18396 PGJI8.MH18396 |
| UL Recognized (US and Canada) | Yes |
| UL-File Number | MH18396 |
| EAN / GTIN | 4031026175843 |
| Labels per Column | 1 |
| Labels per Row | 1 |
| Packaging 1 - Qty | 3000 |
| Packaging 1 - Weight (kg) | 0.68kg |
| Packaging 2 - Qty | 1 |
| Packaging 3 - Qty | 3000 |
| Packaging 4 - Length (m) | 1.20m |
| Packaging 4 - Type | pallet |
| Packaging 4 - Width (m) | 0.80m |
| Weight | 1.48lbs |
| Weight | 0.68kg |
| UNSPSC Key | 55121612 |
