PLS06-PP-RD : PLS06

Article number: 142-00062

Colour Red (RD)
Pack Cont. 100
Package Quantity per pcs.
PART DESCRIPTION PLS06-PP-RD
for Hole ∅ (FH) 16.3 mm
Height (H) 20.60mm
Length (L) 37.6mm
Width (W) 10.00mm
Flammability UL 94 HB
Material Polypropylene (PP)
Operating Temperature - °C -20 °C to +85 °C
EAN / GTIN 5022660313936
Packaging 1 - Height (m) 0.025m
Packaging 1 - Length (m) 0.203m
Packaging 1 - Qty 100
Packaging 1 - Type bag
Packaging 1 - Volume (m³) 0.00077
Packaging 1 - Weight (kg) 0.1500kg
Packaging 1 - Width (m) 0.152m
Packaging 3 - Height (m) 0.17m
Packaging 3 - Length (m) 0.58m
Packaging 3 - Qty 6000
Packaging 3 - Type carton
Packaging 3 - Volume (m³) 0.0375
Packaging 3 - Weight (kg) 9.50kg
Packaging 3 - Width (m) 0.38m
Packaging 4 - Height (m) 0.14m
Packaging 4 - Length (m) 1.20m
Packaging 4 - Qty 120000
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 0.134
Packaging 4 - Weight (kg) 210.0kg
Packaging 4 - Width (m) 0.80m
Weight 1.5kg
ETIM 6.0 EC001288
ETIM 7.0 Key EC001288
