Fixing tie for hole (oval), ⌀2.0-50.0mm, black, 2000pcs.
Art.-No. 157-00521 | T50ROSFTOVAL25SO-PA66HIRHSUV-BK

All-in-one bundling and fastening solution reduces costs and assembly time.
Anti-rotational oval fastener forces bundle to travel in intended direction.
Stand-off cable ties route and position bundles above a mounting hole to protect them from rubbing, heat or obstructions.

Package size

100 pcs.

500 pcs.

2000 pcs.

More products in this product group:

Color	Black (BK)
Description	One-piece stand-off cable tie and mount offers a simple bundling and mounting solution. The innovative design of this fir tree establishes a 360-degree interface with the panel hole, ensuring a more secure fit. The oval shape won’t rotate once inserted, ensuring proper routing of wires and hoses. Stand-off feature positions bundles above a mounting hole. The disc prevents rattling in high-vibration applications and protects against debris ingress.
Min. Tensile Strength (imperial)	50lbs
Min. Tensile Strength (metric)	222.4N
PART DESCRIPTION	T50ROSFTOVAL25SO-PA66HIRHSUV-BK
Packaging Type	carton
Part No.	157-00521
Product family	1-Piece Tie Assemblies
Product family	Fixing ties for holes
Short Desc.	1-Piece Cable Tie with Oval Fir Tree Mount with Disc, 9.6"L, 6.2 x 12.2 mm; 6.5 x 12.5 mm; 6.5 x 13.0 mm or 7.0 x 12.0 mm Mounting Hole, PA66HIRHSUV, Black, 2000/ctn
Type	T50ROSFTOVAL25SO
UV Resistant	Yes

Disc Diameter (imperial)	0.69 x 0.93"
Disc Diameter (metric)	17.63 x 23.63mm
Fixation Method	Fir Tree for oval holes
Identification Plate Position	none
Length (imperial)	9.6"
Length (metric)	243.8mm
Length 2 (imperial)	0.98"
Length 2 (metric)	25.0mm
Max. Bundle Diameter (imperial)	1.97"
Max. Bundle Diameter (metric)	50.0mm
Max. Hole Depth (imperial)	0.27"
Max. Hole Depth (metric)	6.75mm
Max. Mounting Hole Diameter (imperial)	0.51"
Max. Panel Thickness (imperial)	0.27"
Max. Panel Thickness (metric)	6.75mm
Min. Bundle Diameter (imperial)	0.08"
Min. Bundle Diameter (metric)	2.0mm
Min. Hole Depth (imperial)	0.02"
Min. Hole Depth (metric)	0.6mm
Min. Mounting Hole Diameter (imperial)	0.24"
Min. Panel Thickness (imperial)	0.02"
Min. Panel Thickness (metric)	0.6mm
Mounting Hole Diameter (imperial)	0.24 x 0.48 ", 0.26 x 0.49 ", 0.26 x 0.51 ", 0.28 x 0.47 "
Mounting Hole Diameter (metric)	6.2 x 12.2 mm, 6.5 x 12.5 mm, 6.5 x 13.0 mm, 7.0 x 12.0 mm
Mounting Hole Shape	Oval
Offset Length (imperial)	0.98"
Offset Length (metric)	25.0mm
Panel Thickness (imperial)	0.02 - 0.27"
Panel Thickness (metric)	0.6 - 6.75mm
Releasable Closure	No
Thickness (imperial)	0.06"
Thickness (metric)	1.5mm
Width (imperial)	0.20"
Width (metric)	5.1mm

CE Certification	No
CSA Certified	No
Flammability	UL 94 HB
Material	PA66HIRHSUV
Material	Polyamide 6.6 high impact modified, heat and UV stabilized (PA66HIRHSUV)
Operating Temperature	-40°F to +221°F (-40°C to +105°C)
Operating Temperature, 1000h	+320°F (+160°C)
Operating Temperature, 5000h	+257°F (+125°C)
Operating Temperature, 500h	+329°F (+165°C)
Prop65 Warning	No
REACH Conformity	Yes
ROHS compliant	Yes
UL Recognized (US)	No
