Fixing tie for hole (round), ⌀2.0-35.0mm, black, 1000pcs.
Art.-No. 157-00236
| T50SOSFT5.35-PA66HIRHSUV-BK
Copied
- One piece cable tie and fixing offers a simple and easy to use method of bundling and fixing cables.
- The design of the fir tree ensures a positive and secure fixing into panels with thicknesses from 0.6mm to 6.0mm or threaded blind holes.
- Disc on the top of the fir tree covers the hole and minimizes the ingress of water and dirt.
More products in this product group:
| Application | Primarily designed for fixing cable harnesses in the automotive industry, their simplicity and ease of use has resulted in these parts being used in other industries, for example aviation, switch gear manufacturer, white goods manufacturer. |
| Color | Black (BK) |
| Description | Fir tree mounts with ties cables provide a secure grip in mounting holes and protect against dirt and other impurities. The mount provides low insertion and high extraction force. |
| Min. Tensile Strength (imperial) | 40lbs |
| Min. Tensile Strength (metric) | 180N |
| PART DESCRIPTION | T50SOSFT5.35-PA66HIRHSUV-BK |
| Packaging Type | bag |
| Part No. | 157-00236 |
| Product family | 1-Piece Tie Assemblies |
| Product family | Fixing ties for holes |
| Short Desc. | 1-Pc Cable Tie/Fir Tree Mount, 6.0" Long, 0.2 - 0.22" Mounting Hole, PA66HIRHSUV, Black, 1000/pkg |
| Type | T50SOSFT5.35 |
| UV Resistant | Yes |
|
|
|
| Cable Tie Closure | plastic pawl |
| Disc Diameter (imperial) | 0.64" |
| Disc Diameter (metric) | 16.3mm |
| Fixation Method | Fir Tree |
| Identification Plate Position | none |
| Length (imperial) | 6.4" |
| Length (metric) | 163.0mm |
| Length 2 (imperial) | 5.85" |
| Length 2 (metric) | 148.7mm |
| Max. Bundle Diameter (imperial) | 1.38" |
| Max. Bundle Diameter (metric) | 35.0mm |
| Max. Hole Depth (imperial) | 0.23" |
| Max. Hole Depth (metric) | 6.00mm |
| Max. Mounting Hole Diameter (imperial) | 0.22" |
| Max. Panel Thickness (imperial) | 0.23" |
| Max. Panel Thickness (metric) | 6.00mm |
| Min. Bundle Diameter (imperial) | 0.08" |
| Min. Bundle Diameter (metric) | 2.0mm |
| Min. Hole Depth (imperial) | 0.02" |
| Min. Hole Depth (metric) | 0.60mm |
| Min. Mounting Hole Diameter (imperial) | 0.20" |
| Min. Panel Thickness (imperial) | 0.02" |
| Min. Panel Thickness (metric) | 0.60mm |
| Mounting Hole Diameter (imperial) | 0.20 - 0.22 " |
| Mounting Hole Diameter (metric) | 5.35 mm |
| Mounting Hole Shape | Circular |
| Panel Thickness (imperial) | 0.02 - 0.24" |
| Panel Thickness (metric) | 0.6 - 6.0mm |
| Releasable Closure | No |
| Thickness (imperial) | 0.05" |
| Thickness (metric) | 1.32mm |
| Width (imperial) | 0.18" |
| Width (metric) | 4.6mm |
| Width 2 (imperial) | 0.24" |
| Width 2 (metric) | 6.0mm |
Download
| CE Certification | No |
| CSA Certified | No |
| Flammability | UL 94 V-2 |
| Material | PA66HIRHSUV |
| Material | Polyamide 6.6 high impact modified, heat and UV stabilized (PA66HIRHSUV) |
| Operating Temperature | -40°F to +221°F (-40°C to +105°C) |
| Operating Temperature, 1000h | +320°F (+160°C) |
| Operating Temperature, 5000h | +257°F (+125°C) |
| Operating Temperature, 500h | +329°F (+165°C) |
| Prop65 Warning | No |
| ROHS compliant | Yes |
| UL Listed (US and Canada) | No |
| UL Listed (US) | No |
| UL Recognized (US and Canada) | No |
| UL Recognized (US) | No |
