End Caps
Art.-No. 416-18019
| 1618-1-B8W-PO-X-BK
Copied
- End caps are used to seal cables during storage or transportation.
- Helashrink 1600 Series end caps can be used as an insulating cap for live LV cables (0.6/1kV).
- The adhesive lined end caps provide an excellent environmental seal.
- The outer end seal is marked with lightning flashes to indicate live circuit.
- End caps can be fitted with air valves for certain pressurised cable applications.
- The high shrink ratio end caps minimise the number of end cap sizes needed.
More products in this product group:
| Application | End caps are suitable for use on both polymeric and paper insulated, lead jacketed cables which may include aluminium or steel armouring. |
| Brand Family | HELASHRINK |
| Color | Black (BK) |
| PART DESCRIPTION | 1618-1-B8W-PO-X-BK |
| Packaging Type | bag |
| Part No. | 416-18019 |
| Product family | Insulation |
| Type | 1618-1-B8W |
|
|
|
| ⌀H max. b | 6mm |
| ⌀H min. a | 14mm |
| Flexibility | Semi rigid |
| For Object Outside Diameter | 7.6-12.4 mm |
| HW ± 20 % | 2.3mm |
| HW ± 20% | .09" |
| Max Voltage | 600V |
| Max. Bundle Diameter (metric) | 11.0mm |
| Max. Recovered Diameter b | .23" |
| Min. Bundle Diameter (metric) | 6.0mm |
| Min. Supplied Diameter a | .55" |
| P ± 10 % | 55.3mm |
| P ± 10% | 2.16" |
| Recovered Diameter (metric) | 6.0mm |
| Shrink Ratio | up to 3:1 |
| Supplied Diameter (metric) | 14.0mm |
