Fixing tie for edge, inside serrated, ⌀1.0-45.0mm, black, 500pcs.
Art.-No. 156-02494 | T50REC20-PP/PA66HIRHS-BK

Copied
Cable tie with edge clip eliminates the need for drilling mounting holes, simplifying installation.
Fixing Tie with EdgeClip for thick edges.
Five sizes (0.5 - 8.0 mm panelthickness) in one picture.

    • Edge applications don’t require additional fasteners or hole drilling.
    • Low push-on force reduces repetitive strain injuries.
    • Two-piece assembly allows mount to slide along strap, ensuring proper orientation.
    Add to watchlist
    Downloads e-Learning
    Application These cable ties and EdgeClip assemblies are ideal for use where holes are not acceptable or where due to temperature problems adhesives will fail. These assemblies are widely used for fixing and bundling cables, pipes and hoses within the automotive industry, harness making, panel building and electrical industry.
    Color Black (BK)
    Description HellermannTyton's Two-Piece Edge Clip with Cable Tie assemblies are designed specifically to route bundles by securing them to the edge of a plastic or metal sheet without the need for a mounting hole. The clip is easy to secure, and the pull-off strength is high due to the integrated metal clamp that holds the edge clip in place.
    Key product features for narrow bundling
    Min. Tensile Strength (metric) 110N
    PART DESCRIPTION T50REC20-PP/PA66HIRHS-BK
    Packaging Type bag
    Part No. 156-02494
    Product family 2-Piece Tie Assemblies
    Product family Edge fixation products
    Type T50REC20
    Fixation Method EdgeClip, top, assembled, 2 piece
    Height (metric) 1.2mm
    Height 2 (metric) 17.8mm
    Identification Plate Position none
    Length (metric) 200.0mm
    Length 2 (metric) 14.8mm
    Max. Bundle Diameter (metric) 45.0mm
    Max. Panel Thickness (metric) 6.00mm
    Min. Bundle Diameter (metric) 1.0mm
    Min. Panel Thickness (metric) 3.00mm
    Width (metric) 4.6mm
    Width 2 (metric) 14.0mm
    Material PP, PA66HIRHS
    Material Polypropylene (PP), Polyamide 6.6, high impact modified, heat stabilized (PA66HIRHS)
    Material Foot Part PA66HIRHSUV
    ROHS compliant Yes
    Pkg. Qty. 500Pieces
