Fixing tie with pipe/tube holder, inside serrated, ⌀45.0mm, black, 500Set
Art.-No. 156-00989 | T50RIAHC3TSET-PA66HS/PA66HIRHS-BK

Copied

    • Clamp provides low insertion and high extraction force.
    • Various sizes available to accommodate all different sizes of bundles.
    • Clamp can be installed both before and after installation of bundles.
    Add to watchlist
    Downloads
    Application These 2-piece ties are a quick and easy method of fixing and bundling cables. Originally developed for the automotive industry.
    Brand Family IAHC-Series
    Color Black (BK)
    Content 500 T50R + 500 IAHC3T
    Description HellermannTyton’s 2-Piece Cable Tie with Pipe Clip secures cables to tubular frame rails. The cable tie bundles wires, cables or tubes, and the C-clip snaps onto the tubular frame rail. The clip can be removed from the mounting surface and reinstalled without additional fasteners.
    Key product features rotatable, for multiple routing, removable
    PART DESCRIPTION T50RIAHC3TSET-PA66HS/PA66HIRHS-BK
    Packaging Type bag
    Part No. 156-00989
    Product family Omega Clips
    Product family Products for wires and hoses
    Type T50RIAHC3TSET
    Cable Tie Closure plastic pawl
    Fixation Method Omega Clip
    Identification Plate Position none
    Max. Bundle Diameter (metric) 45.0mm
    Releasable Closure No
    Material PA66HS, PA66HIRHS
    Material Polyamide 6.6 heat stabilized (PA66HS), Polyamide 6.6, high impact modified, heat stabilized (PA66HIRHS)
    ROHS compliant Yes
    Pkg. Qty. 500Set
    Cable holder Cable holder

    Cable holder

    Looking for a secure way to fasten cables or wires? Our plastic cable holders are easy to install and suitable for almost any application. Learn more...

    Cable holder >
    Art.-No.: 156-00989 Contact
