Labels for Laser Printers : TAG10L

Self Laminate Label, Article number: 594-10105

Features

  • Crisp and clear text, barcodes and graphics
  • Used to identify wide range of electrical and electronic products
  • Clear protective box to ensures labels stay as good as new
  • Simple and efficient label design and printing with TagPrint Pro software
  • Self Laminate

Certifications & Approvals

Application

This range of labels has been specially developed for use with laser printers. The material properties ensure print is instantly smudge resistant so can be handled immediately. Using laser printers allows users to print barcodes, graphics and condensed text.
A range of sizes and materials are available to suit most cable marking and asset identification needs.
For problem-free printing, we recommend our easy to use windows based TagPrint Pro software program, which comes pre-loaded with all our standard label templates so you can start producing labels immediately.

Colour White (WH)
Colour Marking Field White (WH)
For Wire Type 4 Pair UTP / STP / 25 Pair Copper / 4-12 Pair Fiber
Pack Cont. 1000
Package Quantity per pack
Paper Format Letter
PART DESCRIPTION TAG10L-105-WH
Product Family Self Laminate Label
Product Group Labels for Laser Printers
Bundle ∅ max. 2.20mm
Bundle ∅ min. 1.50mm
Core diameter from / to 6.1 - 12.10mm
H printable 19.06mm
Height (H2) 57.15mm
HR 50.8mm
HR 2.0"
Outside ∅ max. 0.24"
Outside ∅ max (OD max.) 12.10mm
Outside ∅ min. 0.24"
Outside ∅ min. (OD min.) 6.1mm
Print Method Laser printer
Thickness (T) 35.0µm
VR 2.25"
VR 57.20mm
Width (W) 50.8mm
Width of Liner (WL) 215.00mm
Width of LIner (WL) 8.5"
Adhesive Acrylic
Adhesive Operating Temperature -40 °C to +150 °C
CSA Certified No
Curing Temperature +10 °C
Halogenfree No
Material Type 105, Polyester (PET), white (WH)
Operating Temperature - °C -40 °C to +149 °C
Specifications
UL Listed (US and Canada) No
UL Recognized (US and Canada) No
Labels per Column 4
Labels per Row 4
Labels per Sheet 16
Packaging 1 - Weight (kg) 0.521kg
Sheets per Pack 63
Weight 1.14lbs
Weight 0.521kg
ETIM 6.0 EC001530
ETIM 7.0 Key EC001530
UNSPSC Key 55121612
